11 1005-0 Pull-out unit for pallet rack with 70% extension ,1000 kg load capacity, Front-loaded, long-side handled EUR-pallet

- +
Product added to cart
ART No: 11 1005-0 Categories: ,
Arrow

Description

Arrow

Beam-mounted (BM) units are mounted on the cross-beams between
the pallet racking uprights. The lower frame of the pull-out unit is
bolted to the beams and the upper frame slides out carrying the
pallet with it.
Pallets may be loaded directly onto the units, but other options allow
for storage on open shelving, in plastic bins and in cartons. Being able
to pull the units out of the rack allows for safe and easy access to
stored items!
BM units are available in a range of capacities up to 1500kg and in
a variety of formats to suit your requirements. They can cater for
all pallet sizes and types (wood, steel, plastic), front or rear loading
at the pallet rack, short or long-side handling, as well as for pallet
collars with dividers, containers, bins and loose storage. The base
frame BM unit is for pallets.

Arrow

Product Features

Arrow
WEIGHT CAPACITY Manual
1000 kg
EXTENSION Manual
70%
LOAD METHOD ManualManualManual
Forklift | Overhead crane | Pallet stacker
TYPE OF LOAD Manual
EUR-pallet
LOADING Manual
Front loaded
LOAD WAY Manual
One-way
PICKING METHOD ManualManual
By hand | Overhead crane
SHORT OR LONG SIDE HANDLED Manual
Long side handled
Arrow

Technical Specification

Arrow
LOADING WIDTH
Manual
1234 mm
LOADING DEPTH
Manual
880 mm
HEIGHT
Manual
91 mm
RACK DEPTH
Manual
650 mm - 850 mm
WIDTH
Manual
1234-mm
DEPTH
Manual
890 mm
LOADING HEIGHT
Manual
91 mm
Arrow

Weight and Volume

Arrow
PRODUCT WEIGHT
Manual
52-kg
QUANTITY AT PALLET
Manual
8-pcs
PACKAGE WEIGHT
Manual
494kg
NUMBER OF PALLETS /TRAILER
Manual
25
PACKAGE SIZE
Manual
130x95x120
Arrow

Weight Capacity Support Beam

Arrow
OBS! ONLY ONE UNIT PER SECTION MAY BE EXTRACTED AT A TIME!
1 PALLET
Manual
2486kg
2 PALLET
Manual
3572kg
3 PALLET
Manual
4658kg
