Beam-mounted pull-out unit 70%, 1000 kg, Short-side handled, Rear-loaded, for wire mesh containers
Product added to cart
Description
This Beam-mounted pull-out unit with 1000 kg load capacity is built to handle wire mesh containers with demanding point loads. Strengthened side profiles and safety edges keep goods stable during storage and handling. Being short-side handled and rear-loaded, it is perfectly suited for workflows where loading is done from one side of the rack and goods are picked from the opposite side.
The 70% pull-out capacity ensures safe, ergonomic, and efficient access. Extended, it provides an opening of 840 mm, simplifying manual handling. Fits containers with a depth of 1200 mm and width of 800 mm, short side forward.
Product Features
Extension
70%
Handled
Manual pull-out unit
Load Way
One-way
Loading
Rear loaded
Load metod
Forklift, Overhead crane, Pallet stacker
Weight capacity
1000 kg
Picking Method
By hand, Overhead crane
Short or long side handled
Short side handled
Type of load
Gitterbox
Technical Specifications
Depth
Frame Colour
Height
Loading Depth
Loading height
Loading Width
Width
Rack Depth
Weight and Volume
Number of pallets / Trailer
Pallet Size
Pallet weight
Product Weight
Quantity on pallet
Weight Capacity Support Beam
WCSB 1 pallet
2486 kg
WCSB 2 pallets
3572 kg
WCSB 3 pallets
4658 kg
