13 1004 floor mounted pull-out unit ,1000 kg, Rear-loaded, short-side handled FIN-pallet

- +
Product added to cart
ART No: 13 1004 Categories: ,
Arrow

Description

Arrow

Floor-mounted (FM) units fit under the rack and are compatible with almost any type of pallet racking, but can also be used as freestanding units. They are fixed to the floor with bolts through the lower frames, which act as rails for the upper frames to slide out on bearings, and are supported by high quality pallet truck wheels at the front. Being able to pull the units out of the rack allows for safe and easy access to stored goods! Cost-saving ergonomics are a primary consideration with FM units, as with all Smart Storing designs. Each model uses the right sizes and numbers of quality ball bearings, so they’re strong, reliable and easy to slide in and out. Guide rails ensure the units stay in line when pulled out, and can be pushed back in without effort. A safety latch is automatically engaged when the unit is in the rack. This prevents the unit from being unintentionally pushed out from the other side of the rack. (This feature is especially important when using rear loaded units or units placed in a double rack, where they can be hit from behind when loading the opposite unit).

Arrow

Product Features

Arrow
WEIGHT CAPACITY Manual
1000 kg
EXTENSION Manual
85%
LOAD METHOD ManualManualManualManual
Forklift | Hand pallet truck | Overhead crane | Pallet stacker
TYPE OF LOAD Manual
FIN-/ CHEP-pallet
LOADING Manual
Rear loaded
LOAD WAY Manual
One-way
PICKING METHOD ManualManual
By hand | Overhead crane
SHORT OR LONG SIDE HANDLED Manual
Short side handled
Arrow

Technical Specification

Arrow
LOADING WIDTH
Manual
1030 mm
LOADING DEPTH
Manual
1204 mm
HEIGHT
Manual
68 mm
Arrow

Weight and Volume

Arrow
PACKAGE WEIGHT
Manual
378kg
NUMBER OF PALLETS /TRAILER
Manual
25
QUANTITY IN THE PACKAGE
Manual
12pcs
PACKAGE SIZE
Manual
125-x-110-x-125
